Seal

Product details

   Description:

• A bushing seal is a ring seal with a variable cross - section geometry designed to prevent leakage and contamination.

     Features:

• Cat® bushing seals are made of an elastic material consistent with the oil and temperature of the Cat engine.

• Our seals and rings adhere to a strict tightness tolerance to ensure that they are properly inserted into the seal groove with the necessary seal compression.

• The Cat® sealing system USES a robust design, test and validation process.Please purchase the latest Cat® original seals to protect your investment.

   Application:

• Bushing seals are used in Cat® engines.

Compatible with the type

• Wheel loader

• 988H 988K 980H

• Cold milling planer

• PM620 PM-200

• Caterpillar bulldozer

• D10T D9T D8T

• Crawler excavator

• 374D L 390F L 390D L

• excavator

• 374F L

• Off-road truck

• 773E 772G

Product specification

• Material: EPDM - EPDM - EPDM rubber

• Outside diameter (mm) : 132

• Material description: EPDM provides excellent performance in coolant/urea applications and is also suitable for air applications.Do not use in engine oil, diesel oil, hydraulic oil, automatic transmission fluid or biodiesel.Good wear resistance and cutting resistance.

• Note: Dimensions and material description are for reference only.The color may differ from the picture.

• Width of cross section (mm) : 6.2

• Height of cross section (mm) : 1.1

• Inner diameter (mm) : 130.2
